Pulsar ULTRA 5 User Manual

Page 113
To program the Flow 5 for Example 1 V-Notch Weir by using the Quick
Setup menu proceed as follows.
If required access the Program Mode
Key in the passcode 1997 and press ENTER
Using the ‘right’ arrow key go to the Quick Setup menu press ENTER and
as prompted, by the questions, select the relevant option and press ENTER.
Question
Option
PMD Type
1 = Exponent
Exponent
6 = V notch.
Calculation
2 = Ratiometric.
No. of Alarms
0 = No Alarms
Xducer
1 = dB Mach3
Volume Units
1 = Litres
Time Units
1 = Per Second
Measnt. Units
1 = metres
Empty Level
1.000 metres
Minimum Head
0.000 metres
Maximum Head
0.400 metres
Total Enable
1 = On
Totaliser (R)
0 = No
Total Multiplier
7 = 1000
Maximum Flow
96.5
Programming is now complete and the unit can now be returned to the run
mode, press CANCEL until Run Mode? Is displayed on the LCD press
ENTER, and the Flow 5 will return to Run Mode.
