Page 168
P215, P225, P235, P245, P255 Relay Setpoint 3
P211, 221, 231, 241, 251 = 4 (Flush Valve)
Enter desired Flush duration in seconds.
See the appropriate relay Function tables (P211, 221, 231, 241, 251) for
further information.
P211, 221, 231, 241, 251 = 5 (Step Time)
This parameter is used to determine the Limit Time between each Drive Period.
Relay Setpoints are entered in Minutes, during which time the relay will remain
OFF.
See the appropriate relay Function tables (P211, 221, 231, 241, 251) for
further information.
When Ultra Wizard = 3 Flow
P213, P223, P233, P243, P253 Relay Setpoint 1
P211, 221, 231, 241, 251 =2 (Step Time)
Relay Setpoint 1 is entered in values of Measurement Units (P104)
See the appropriate relay function tables (P211, 221, 231, 241, 251) for further
information.
P214, P224, P234, P244, P254 Relay Setpoint 2
P211, 221, 231, 241, 251 =2 (Step Time)
Relay Setpoints are entered in Seconds to set Drive Period, the time that the
relay will remain ON
See the appropriate relay Function tables (P211, 221, 231, 241, 251) for further
information.
P215, P225, P235, P245, P255 Relay Setpoint 3
P211, 221, 231, 241, 251 = 2 (Step Time)
This parameter is used to determine the Limit Time between each Drive Period.
Relay Setpoints are entered in Minutes, during which time the relay will remain
OFF.
See the appropriate relay Function tables (P211, 221, 231, 241, 251) for
further information.
