Page 167
P214, P224, P234, P244, P254 Relay Setpoint 2
P211, 221, 231, 241, 251 =1 (Time)
This parameter determines the “Cycle Time ” for the operation of the relay.
See the appropriate relay Function tables (P211, 221, 231, 241, 251) for further
information.
P211, 221, 231, 241, 251 =2 (Storm)
Relay Setpoints are entered in values of Measurement Units (P104)
See the appropriate relay Function tables (P211, 221, 231, 241, 251) for further
information.
P211, 221, 231, 241, 251 =3 (Aeration)
Relay Setpoints are entered in Minutes to set Time Period that the relay will
remain ON
See the appropriate relay Function tables (P211, 221, 231, 241, 251) for further
information.
P211, 221, 231, 241, 251 =4 (Flush Valve)
Relay Setpoints are entered in cycles to set the number of Flush cycles.
See the appropriate relay Function tables (P211, 221, 231, 241, 251) for further
information.
P211, 221, 231, 241, 251 =5 (Step Time)
Relay Setpoints are entered in Seconds to set Drive Period, the time that the
relay will remain ON
See the appropriate relay Function tables (P211, 221, 231, 241, 251) for further
information.
P211, 221, 231, 241, 251 =6 (Differential)
Relay Setpoints are entered in values of Measurement Units (P104)
See the appropriate relay Function tables (P211, 221, 231, 241, 251) for further
information.
