The fourth parameter, fifth parameter and sixth parameter are set to
determine the switch points, “ON” and “OFF” for the relay and where
required the order of start. See control function, table (P211, 221, 231) for
further information.
When Ultra Wizard = 2 Pump/Differential
P213, P223, P233, P243, P253 Relay Setpoint 1
P211, 221, 231, 241, 251 =1 (Time)
This parameter determines the “Time Period” that the relay will remain
“ON”.
Relay Setpoints are entered in Minutes.
See the appropriate relay Function tables (P211, 221, 231, 241, 251) for
further information.
P211, 221, 231, 241, 251 =2 (Storm)
Relay Setpoint 1 is entered in values of Measurement Units (P104)
See the appropriate relay function tables (P211, 221, 231, 241, 251) for
further information.
P211, 221, 231, 241, 251 =3 (Aeration)
Relay Setpoint 1 is entered in Minutes to set Cycle Time
See the appropriate relay Function tables (P211, 221, 231, 241, 251) for
further information.
P211, 221, 231, 241, 251 =4 (Flush Valve)
Relay Setpoint 1 is entered in Pump cycles to set Flush Interval.
See the appropriate relay Function tables (P211, 221, 231, 241, 251) for
further information.
P211, 221, 231, 241, 251 =5 (Step Time)
Relay Setpoint 1 is entered in values of Measurement Units (P104)
See the appropriate relay function tables (P211, 221, 231, 241, 251) for further
information.
P211, 221, 231, 241, 251 =6 (Differential)
Relay Setpoint 1 is entered in values of Measurement Units (P104)
See the appropriate relay function tables (P211, 221, 231, 241, 251) for further
information.
