Pulsar ULTRA 5 User Manual

Page 73
Wait ….
Parameter
Default
Description
P101 Transducer
2 = dB6
Type of transducer being used.
P104
Measurement
Units
1 = metres
Select units to be used for
programming measurement
information.
P105
Empty Level
6 m
Distance from the face of the
transducer to the material at the
bottom of the vessel.
P106
Span
5.7 m
Distance from the empty level (0%
full) to span (100% full).
For More Options Hit Enter
Parameter
Default
Description
P213 / P214
Relay 1
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Either Alarm or Pump control.
Depends on application.
P223 / P224
Relay 2
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Depends on
application
Either Alarm or Pump control.
Depends on application.
P233 / P234
Relay 3
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Depends on
application
Either Alarm or Pump control.
Depends on application.
P243 / P244
Relay 4
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Depends on
application
Either Alarm or Pump control.
Depends on application.
P253 / P254
Relay 5
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Depends on
application
Either Alarm or Pump control.
Depends on application.
