The pages are divided into chapters, where they are numbered con‐
secutively.
Example: 3 – 2 (chapter 3 – page 2)
© Putzmeister Mörtelmaschinen GmbH
1.2 Icons and symbols
The following icons and symbols are used:
Icon/symbol/
designation
Meaning
▶ Individual instruction or alternative step.
1. 2. 3. Instructions to be carried out as described in the
specified sequence.
⇒ Result or intermediate result of previous steps.
➙ Result of an instruction or of several steps.
● Marking for simple lists.
Cross refer‐
ence
(Icons and
symbols
P. 1 — 3)
Cross references refer to chapters, sections or
figures, for example. A cross reference is depic‐
ted in brackets.
Fault rectification – Instructions to be carried out
in accordance with fault messages.
View additional steps. For example, “Contact a
qualified electrician”.
✓ Inspection or maintenance activity must be car‐
ried out.
Guide to the Operating Instructions
1 — 3
