3.8 Control devices
This section provides a summary of the different control devices on
the machine.
Figure 8: Control devices (different models available)
Item Designation
1 Control cabinet
2 Water valve fitting
3 Water pump
4 Compressor
5 Air valve fitting (hidden)
6 Spray gun
The data refers to the series machines. These may vary for special
equipment. You can also find the data on the machine card sup‐
plied with the machine.
3.9 Control cabinet
The machine is operated and controlled from the control cabinet.
General technical description
3 — 11
