The power source must fulfil the following criteria:
● The power source is equipped with a residual current device
(RCD).
● The connected load of the existing electrical installation must be
sufficient for the machine. Please refer to the technical data for the
maximum pre-fuse.
● All three phases and the protective earth conductor must be pres‐
ent.
4.9.2 Electrical supply cables
Supply cables must be laid neatly, taking local conditions into consid‐
eration, and safeguarded against damage.
DANGER
Risk of death due to fatal electric shock from damaged cables
If cables are installed unprotected on the construction site, they may
be damaged by environmental or mechanical factors.
▶
Install cables from the power source to the machine such that
they are safe and protected.
▶
Make sure that the cables are installed such that they are pro‐
tected from mechanical damage and environmental influences.
If necessary, install the cables in cable ducts.
DANGER
Risk of death due to fatal electric shock from control cabinets and
terminal boxes
It is possible to come into direct contact with live parts on control
cabinets and terminal boxes.
Please note that the control cabinet can only be opened with a spe‐
cial key or tools.
▶
Only qualified personnel may open the control cabinet.
Transport, setting up and connection
4 — 20
