5.1.1.1 Screw-in aid
A screw-in aid for the screw conveyor parts is permanently welded to
the frame. The screw-in aid retainer keeps the screw conveyor barrel
securely in position so that the screw conveyor can be screwed into
the screw conveyor barrel with both hands. A slit in the screw-in aid
secures the screw conveyor barrel at its anti-rotation device so that it
cannot turn when screwing in the screw conveyor.
Figure 25: Screw-in aid with screw conveyor barrel
5.1.2 Mounting the auger pump on the mixing pipe
Before mounting the auger pump on the mixing pipe, the mixer shaft
must be removed from the mixing pipe.
