3.4 Rating plate
The most important machine specifications are shown on the rating
plate.
Figure 5: Rating plate
Item Designation
1 CE marking (product complies with European regulations)
2 EAC marking (product complies with the technical regulations of the
Eurasian Economic Union)
3 Model (machine model)
4 Machine no. (machine number)
5 Year of manufacture
6 Max. delivery pressure [bar]
7 Voltage [V]
8 Frequency [Hz]
9 Power [kW]
10 Weight [kg]
General technical description
3 — 6
