5.4.3 Function check of the tilt switch
Your machine is fitted with a tilt switch. Check the function of the tilt
switch by proceeding as follows.
Item Designation
1 Turnbuckle
1. Start the drive motor. ( Starting the motor P. 5 — 10)
2. Open the turnbuckle to open the mixer motor.
3. Open the mixer motor sideways.
⇒
The mixer motor must stop immediately.
When the tilt switch reacts in this way, the machine is stopped nor‐
mally. The electrical drive power supply is not interrupted.
4. Switch the machine off at the main switch.
5. Close the mixer motor again.
Align the mixer shaft retainer on the mixer motor and the mixer
shaft.
6. Close the turnbuckle to secure the mixer motor.
5.5 Shutting down the machine after starting up
After the function check, you can shut down the machine.
1. Switch off the pump using the “Pump ON – OFF” double push-
button.
Starting up
5 — 13
