Item Designation
1 Water pump
2 Water filter
3 Water pump water connection
4 Connection – water removal
5 Ball valve – water removal
6 Water pump outlet
The electrically driven water pump is used as a pressure booster
pump in case the pressure in the water network is not sufficient.
The water pump is a suction pump that draws the water in itself.
3.13.1 Water filter
The water filter guarantees an improved level of water purity. Check
the water filter regularly and replace it as required.
Item Designation
1 Open water filter
General technical description
3 — 20
