3.15 Spray gun
The spray gun is attached to the end of the delivery line.
Figure 16: Spray gun overview
Item Designation
1 Rubber fine plaster nozzle
2 Delivery line connection
3 Material lever (dependent on model)
4 Remote control valve
5 Air supply coupling
6 Stop cock (dependent on model)
7 Air-regulation cock (dependent on model)
