If your machine is not equipped with an EMERGENCY STOP but‐
ton, switch the machine off at the main switch when an impending
danger arises. Switching the machine off at the main switch cau‐
ses an EMERGENCY STOP.
3.6.3 Tilt switch
The machine is fitted with a tilt switch. A tilt switch is installed in the
gear motor; if the mixing pipe begins to swivel away, this switches off
the motor.
When the tilt switch reacts in this way, the machine is stopped nor‐
mally. The electrical drive power supply is not interrupted.
3.7 Description of the functions
The following sections are intended to help you understand the op‐
erational sequences of the machine so that you can limit the field of
application of the machine to suitable areas and avoid faults in opera‐
tion.
The machine is easy to set up and operate. However, you must take
certain precautions during operation in order to achieve the maximum
possible service life of the wear parts.
The mixing pump is a machine designed for processing premixed dry
mortar. It mixes, pumps and sprays continuously.
The machine is filled via the hopper. From here, the dry mortar is con‐
veyed to the mixing pipe. The adjustable volume of water is added via
a fitting with a flow meter. The dry mortar is mixed with water. Next,
the mixed mortar is pumped by an auger pump.
A spray gun can be attached to the end of the delivery hose. Air is
introduced from the compressor and the mortar applied in the desired
layer thickness.
General technical description
3 — 10
