Item Designation
1 Mixing pipe
2 Threaded sleeve
3 Auger pump pressure connection unit
7. Hang the auger pump pressure connection unit on the mixing
pipe flange using the threaded sleeves.
Item Designation
1 Threaded sleeve
2 Auger pump pressure connection unit
8. Tighten the two threaded sleeves on the auger pump pressure
connection unit securely and evenly on the mixing pipe using a
suitable spanner.
Maintenance
8 — 18
