Item Designation
10 Multiple socket outlet
Pump connection
11 Multiple socket outlet
Agitator connection
12 Selector switch
Water pump (different function depending on connection)
13 EMERGENCY STOP button (dependent on model)
Switching off the machine in an emergency
Figure 10: Symbols on the control cabinet
Item Designation
1 Compressor connection
2 Pump connection
3 Parallel operation of pump/agitator
4 Continuous operation of agitator
5 Main switch ON
6 Main switch OFF
7 Water pump OFF – Automatic
General technical description
3 — 14
