Figure 15: Auger pump with clamping sheath overview
Item Designation
1 Screw conveyor
2 Screw conveyor barrel
3 Clamping sheath
4 Clamping bolts
The wear of the auger pump can be compensated by tightening. You
can also adjust the delivery pressure by pre-tightening or relieving the
tension on the screw conveyor barrel. The “Maintenance” chapter de‐
scribes how to adjust the auger pump.
General technical description
3 — 18
