Item Designation
1 Lifting eye
4.2.2.1 Loading the individual components
The machine can be dismantled into its individual components by two
people
(Dismantling the machine into individual components
P. 4 — 6)
. To transport the individual components with a suitable
crane, proceed as follows:
1. For crane transport, remove the compressor from the base frame.
2. Secure the lifting belts at all four lifting eyes.
3. Raise the load.
Transport, setting up and connection
4 — 4
