Matrix 832 / 832+ / 424
Page 80 RINS428-5
MEANING
Programmable Options Explanation
Telephone numbers
Up to 9 telephone numbers may be programmed with a total length up to 32 digits. Use a comma ( , ) to
denote a 2 second pause.
Reporting Formats
Contact ID - This is a standard events reporting format, the event numbers of which are pre-programmed
automatically.
Handshake Specification of CID
Handshake Frequency = 1400Hz for 100 ms / silence 100 ms / 2300Hz 100 ms.
Handshake Duration Frequency = 100 ms.
Handshake Delay Time = 250 ms.
Handshake Duration Time = 100 ms.
Max. Handshake Wait Time = 40 ms.
Acknowledgement Tone Duration Time = 750 ms.
Contact ID Check Sum = Yes
Digital Event CID Number Sent to the Station Digital Receiver
The digital event code displayed on the station receiver = [AAAA] [CC] [Q] [EEE] [PP] [SSS] [m]
[AAAA] = Account number will first be displayed
[CC] = Reporting format = 18 for CID
[Q] = Event qualifier: “0” – Close / Restoral and “1” - Open / Alarm.
[EEE] = Digital event code
[PP] = Group or partition number
[SSS] = Zone Number / User number
[m] = Check sum
Example digital event CID number displayed on station receiver
R0083 L01 #12345
Trbl
Z# 42
01/01 10:26P *E1/1
