! Matrix 832 / 832+ / 424
RINS428-5 Page 81
Table CID Events Reported by Matrix System
Hexadecimal Event
Number
English Equivalent Notes
Group 1 (Alarm)
QX 130 Normal Alarm Zone
QX 133 24 Hour Alarm Zone
QX 134 Entry / Exit Alarm Zone
QX 137 Alarm From Tamper On Case/Keypad/Expander
QX 143 [Vx.x] Expander Fail
QX 146 Silent Burglary (bell delay)
QX 321 Bell 1 Tamper
QX 383 Sensor Tamper
Group 2 (Personal Attack)
QX 121 Duress Arm / Disarm
QX 122 Silent PA from Keypad or PA Zone
QX 123 No Silent PA from Keypad or PA Zone
Group 3 (Fire)
QX 110 Fire
Group 4 (Maintenance)
QX 301 AC Loss
QX 302 Low Battery
QX 607 Walk Test Mode Entered / Left
QX 627 Engineer Mode Entered
QX 628 Engineer Mode Left
Group 5 (Open / Closing)
QX 401 Open / Close by User
QX 403 Closing On Power Up
QX 409 O/C by Keyswitch Zone
Group 6 (Medical)
QX 100 Medical Alert
Group 7 (Confirmed)
QX 139 [Vx.x] Confirmed Alarm
Group 8 (Omit)
QX 570 Normal Zone Bypassed On Arm
QX 571 Fire Zone Bypassed On Arm
QX 572 24 hour Zone Bypassed On Arm
Test Call
QX 602 Periodic Test Call
QX 250 Keybox & Patrol
BSIA Fast Format – this is a fast reporting format that reports up to 8 general events.
Handshake specification of Fast Format
Handshake Frequency = 1400Hz for 100 ms / silence 100 ms / 2300Hz 100 ms.
Handshake Delay Time = 250 ms.
Max. Handshake Wait Time = 40 ms.
Acknowledgement Tone Duration Time = 750 ms.
Digital event BSIA fast format send to the Station digital receiver
The digital event code displayed on the station receiver = [ACCT] [Q] [XYZ] [GG] [CCC]
[ACCT] = Account number will first be displayed
[Q] = Event qualifier: “1” - New event / operation. “3” New restoral or close. “6” Previous reported of
normal event
[XYZ] = Digital event code
[GG] = Group or partition number
[CCC] = 1. Sensor no 2. User no 3. Set level (arm mode)
Pyronix PC Format – This format is designed to allow the panel to report the same codes as per Contact ID
instead to a Digital Receiver to a PC by using the Pyronix Maintenance & Monitoring software and std. US
Robotics modem supplied by Pyronix.
