882 Video Test Instrument User Guide (Rev A.35) 187
The table below describes the report fields available for the New Report screen.
Generate HTML
Report
Clicking on this button will cause the Format Editor application to generate
an HTML report of the list of formats. A dialog box pops up to allow you to
specify a location and name on your PC.
Edit Format This activation button is only enabled when you select a format from the list.
Clicking on this button will open up the Format Editor window at the Timing
tab.
Use Format This activation button is only enabled when you select a format from the list.
Clicking on this button activate this format in the connected 882 generator.
Report Parameter Parameter Description
Name The format name.
Digital Video
Identification Code
Writes the specified Video Identification Code (VIC) into the AVI InfoFrame.
Horizontal Total The total number of active pixels (Machine) or microseconds (Time) of the
horizontal video. The total is the sum of the Active and Blanking. Parameter:
HTOT.
Horizontal Active The number of active pixels (machine) or microseconds (Time) of the
horizontal video. Parameter: HRES.
Horizontal Sync
Pulse Polarity
Indicates whether the digital horizontal sync pulse polarity is positive going
or negative going. Parameter: HSPP.
Horizontal Rate
(kHz)
The horizontal line rate of the format. The HRAT is the fundamental
frequency in the 882. Parameter: HRAT.
Vertical Total The total number of active lines (Machine) or milliseconds (Time) of the
vertical video. The total is the sum of the Active and Blanking. Parameter:
VTOT.
Vertical Active The number of active lines (machine) or milliseconds (Time) of the vertical
video. Parameter: VRES.
Vertical Sync Pulse
Polarity
Indicates whether the vertical sync pulse polarity is positive or negative
going. Parameter: VSPP.
Vertical Rate The vertical frame rate of the format. Parameter: VRAT.
Sync Type Indicates the sync type of the format. The parameter is SSST.
Button Description / Function
