882 Video Test Instrument User Guide (Rev A.35) 131
3. Press the Tools key and choose the Reports item by pressing the adjacent soft key.
The following is displayed on the 882’s LCD.
4. Select HDCP to access the HDCP compliance test menu.
The following is displayed on the 882’s LCD.
5. Select EditPCP to define the capabilities of the HDCP device under test.
The following is displayed on the 882’s LCD.
The following table describes the test parameters and their settings (gray = N/A).
Parameter Explanation
CTS Version Specifies whether you wish to test to the HDCP CTS 1.1
or HDCP CTS 1.2. Please note you will not be able to
select CTS 1.2 if the HDCP CTS 1.2 option is not
enabled on the 882EA.
DUT type Specifies the type of device under test. This can be one
of Sink, Source, Repeater3AB, or Repeater3C. For this
test, select Sink.
Test Number Specifies which test to run. Or enables you to select all
tests. Please note that Quantum Data highly recom-
mends running the tests individually.
Sink 1.1 Features Supported Indicates whether the sink DUT supports
Advanced_Cipher mode and Enhanced Link Verifica-
tion. The values are + for yes and - for no.
Sink 1.1 Audio Supported Indicates whether the sink DUT supports audio output.
The values are + for yes and - for no.
Sink Short Read Ri Indicates whether the sink DUT will respond to short
reads of the Ri register. The values are + for yes and -
for no.
EDID Packets
Misc HDCP
!CompRpt EditPCP
1.2 :CTS Ver.
Sink :DUT Type
+All :Test Num-
+ :Src Max KSV -
