140 Chapter 13 Testing HDCP on HDMI
The following table describes tests run with the CPTX:CPTR command for the 882EA.
CPTX:CPTR
Index Test Description
21 3A_01 (Repeater Downstream
w/Receiver) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver)
Regular Procedure: With HDMI Capable
Receiver
22 3A_02 (Repeater Downstream
w/Receiver) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver)
Irregular Procedure: (First Part of
Authentication) HDCP Port Access
23 3A_03 (Repeater Downstream
w/Receiver) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver)
Irregular Procedure: (First Part of
Authentication) Verify Bksv
24 3A_04 (Repeater Downstream
w/Receiver) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver)
Irregular Procedure: (First Part of
Authentication) Verify R0’
25 3A_05 (Repeater Downstream
w/Receiver) (Between HDMI
Capable Transmitter and DVI
Receiver)
Regular Procedure: With DVI Receiver
26 3B_01 (Repeater Downstream
w/Repeater)
Regular Procedure: With Repeater
27 3B_02 (Repeater Downstream
w/Repeater)
Irregular Procedure: (Second Part of
Authentication) Timeout of KSV List READY
28 3B_03 (Repeater Downstream
w/Repeater)
Irregular Procedure: (Second Part of
Authentication) Verify V’
29 3B_04 (Repeater Downstream
w/Repeater)
Irregular Procedure: (Second Part of
Authentication) MAX_DEVS_EXCEEDED
30 3B_05 (Repeater Downstream
w/Repeater)
Irregular Procedure: (Second Part of
Authentication) MAX_CASCADE_EXCEEDED
