142 Chapter 13 Testing HDCP on HDMI
2. Activate the HDMI-H interface on the output port as follows:
a. Press the Interface key. A listing of signal interfaces appears on the 882’s display
as shown below.
b. Choose the HDMI-H item by pressing the adjacent soft key. The interface is
activated and the display is shown below.
Alternatively, to activate the interface through the command line interface, enter the
following commands:
XVSI 4 // Activates the HDMI-H interface
ALLU // Applies the interface setting to the 882
3. Press the Interface key repeatedly until the following menu appears:
4. Choose the HDMI IN 1 by pressing the adjacent soft key.
5. Press the Tools key and choose the Reports item by pressing the adjacent soft key.
The following is displayed on the 882’s LCD.
6. Select HDCP to access the HDCP compliance test menu.
The following is displayed on the 882’s LCD.
VGA
HDMI-D
CVBS
S-VIDEO
SDI
*
HDMI-H
VGA
HDMI-D
CVBS
S-VIDEO
SDI
*HDMI-H
HDMI IN 1
HDMI IN 2
*
EDID Packets
Misc HDCP
To Next Page
