200 Appendix A Command Reference
Edit
Parameters (Video Signal)
Command Description
FMTN Create a new format file
FMTB Begin a format editing session
FMTE End a format editing session
FMTS Save a new format to filename specified by FMTN
JDVI Set upper and lower pixel clock rate limit for DVI output
JLDI Set pixel clock rate for LDI output
JRAT Set pixel clock rate
PELD Set number of data bits in each active pixel
HSIZ Set horizontal physical size of image displayed
VSIZ Set vertical physical size of image displayed
USIZ Set measurement units for HSIZ and VSIZ
Command Type Description
XVSI Interface Enable/disable video signal interface output
XVSI:IN Interface Enable/disable video signal interface input
SSST Synchronization Set display sync signal type
GAMC Gamma Correction Enable/disable video gamma correction factor
GAMA Gamma Correction Set video gamma correction factor
CXAR Active Format
(HDMI)
Set aspect ratio of source image content
EXAR Active Format
(HDMI)
Set aspect ratio of extended image content
SXAR Active Format
(HDMI)
Set natural aspect ratio of video signal format
EXCX Active Format
(HDMI)
Map source image to extended image
SXCX Active Format
(HDMI)
Map CXAR-shaped image to SXAR-shaped
aperture
SXEX Active Format
(HDMI)
Map EXAR-shaped image to SXAR-shaped
aperture
XAFD Active Format
(HDMI)
Set parameters to support a given AFD code
