882 Video Test Instrument User Guide (Rev A.35) 201
PXAR? Active Format
(HDMI)
Get aspect ratio of pixels in active regions of
raster image
XBBH Manual Border
(HDMI)
Set bottom border height
XLBW Manual Border
(HDMI)
Set left border width
XRBW Manual Border
(HDMI)
Set right border width
XTBH Manual Border
(HDMI)
Set top border height
PELD Canvas Set pixel depth
NPPP Canvas Set pixel repetition factor
DVST Digital Video Set signal type
DVQM Digital Video Set quantizing mode
NCPP Digital Video Set number of clocks per pixel
NBPC Digital Video Set color depth
LMAX Digital Video Set maximum digital quantizing level
LMIN Digital Video Set minimum digital quantizing level
NLNK Digital Video Set number of links used by LVDI digital outputs
BALG Digital Video Enable/disable adding DC balancing to Open
LVDI digital output
PREG Digital Video Enable/disable pre-emphasis to Open LVDI
digital outputs
DVSP Digital Video Set signal polarity
DVPT Digital Video Set output protocol (DVI or HDMI)
DVSM Digital Video Set sampling mode
DVSS
(OUT1:DVSS,
OUT2:DVSS)
Digital Video Set TMDS differential swing voltage
DSST Digital Sync Set digital separate sync type for digital
composite sync output
DSCT Digital Sync Set composite sync type for digital composite
sync output
HSPP Digital Sync Polarity Set digital horizontal sync pulse polarity
VSPP Digital Sync Polarity Set digital vertical sync pulse polarity
CSPP Digital Sync Polarity Set digital composite sync output polarity
Command Type Description
