RADWIN5000ConfigurationGuide Release4.9.17 B‐2
FigureB‐1:AirInterfaceTabforFCCUCBP
ThroughputMode:LeavethisasMaximumThroughput
SharingPercentage[%]:Thisvalue(between15‐75%,default50%)isthemaximumcapacity
theHBSispreparedtorelinquishinfavourofothertransmittersonthisband.(There
maybeseveral.)
MinimalContention:Thisvalue(5‐20ms,default10ms)istheamountoftimetheHBSis
preparedtowaittocheckagainforchannelavailability‐andifstillnotavailable,to
transmitregardless.
ThevaluesassetinFigure B‐1meanthefollowing:TheHBSwi ll relinquish20%ofits
capacity,butwilltransmitaburstafter10msregardless.

Radwin 5000 Specifications

General

Channel Bandwidth	5 MHz, 10 MHz, 20 MHz, 40 MHz
Encryption	AES
Product Type	Point-to-Point
Interface	Ethernet
Frequency Bands	5.1 GHz, 5.4 GHz, 5.8 GHz
Modulation	Adaptive Modulation (QPSK to 256QAM)
