Service error code:
Service 10 SC-Pump without Function
Service 11 level electrode (Osmosis water) or check
valve above steam generator for leakage
Service 12 CDS sensor no output signal
Service 13 change level electrode
Service 14 Level electrode (Osmosis water)
Service 16 since 01-07-09,
ash new software version rst
Service 17 external EEPROM faulty
Service 20 thermocouple B1 faulty
Service 21 micro switch clima control faulty
Service 22
Service 23 SSR steam short circuit
Service 24 SSR hot air short circuit
Service 25 CleanJet water circulation faulty
- water doesn‘t hit fan wheel
- check pump, foreign bodies in water
pipe, racks / trolley must be inside cabinet
Service 26 drain valve closed
Service 27 drain valve doesn‘t close,
CleanJet without function
Service 28 B5 in steam generator above 180°C
(356°F), de-scale steam generator
Service 29 pcb temperature too high
(above 85°C / 185°F); change air lter
Service 30 humidity control faulty
Service 31.X core probe faulty
Service 32.X ignition box faulty, change ignition box
0-top; 1-bottom; 2-both
Service 33.X 4x Reset without function,
change ignition box; 1-top; 2-bottom
Service 34.X BUS signal error
1-I/O pcb, 2-motor bottom; 4-motor top;
8-ignition box top; 16-ignition box bottom
Service error code:
Service 40 Cleanjet not possible,
Care pump faulty
Service 41 CDS does not send any pulses; solenoid
valve Y3 defective or moistening valve
blocked;
Service 42 CDS does not send any pulses; Solenoid
Y4 Care defective or hose to care contai-
ner blocked up or kinked;
Service 43 CDS sensor sends always pulses; Soleno-
id Y1, Y3 or Y4 is passing water
Service 44 Steam heating or SSR faulty
Service 100 Main contactor - pcb on off switch
Service 110 SC pump faulty or level electrode calci es
Service 120 Care Pump M12 or level electrode defec-
tive
Gas-settings - values
Dyn. pressure LPG 27-57 mbar; 2,7-5,7 kPa
Dyn. pressure natural gas 18-25 mbar; 1,8-2,5 kPa
CO2 max LPG
(G30) 3BP
10,4% +/- 0,2% for type 61-202
CO2 max LPG
(G31) 3P
11,1% +/- 0,2% for type 61-202
CO2 max natural gas H
(G20)
9,4% +/- 0,2% for type 61-201
9,5% +/- 0,2% for type 202
CO2 max natural gas L
(G25)
9,3% +/- 0,2% for type 61-201
9,4% +/- 0,2% for type 202
Calibration SCC
Calibration at the customers site must be done under the
following conditions: Changing of:
1 Pressure sensor P1,
2 B4 humidity sensor,
3 fan motor,
4 pcb,
5 external EEPROM,
6 detaching of the fan wheel,
7 replacing the air baf e or divider plate between the 2 fan
motors of a oor model,
8 installation of the appliance above 1000m (3000ft) above
sea level or below sea level (dead sea),
installing with Ultravent of
venting extension or as a Combi Duo
9 Usage of a different standard rack
10 Customer complaint for uneven cooking results
Basic condition Temperatures:
Cabinet sensor Quench. sensor Humidity sensor
B1 <40°C B2 <45°C B4 < 40°C
Basic condition Hardware:
Heating: OFF Fan motor: OFF Humidity ap: Closed
Side panel must be tted; Unit must be clean, but may be wet
In order to achieve the best possible calibration values, insert
2 GN-container 20 or 40 mm deep with the opening facing
downwards
in 61 and 62 units into rail 2 and 5
in 101 and 102 units into rail 3 and 7
in 201 and 202 units 3 GN container into rail 3, 10 and 17
To start calibration: Set DIP switch 1 in on pcb, Select:
Basic Settings, Pkt. 1.1: START
