19
Models
USER GUIDE
GETTING STARTED
SMART-SENSOR
™
2004 – 2014 Reliable Controls
®
Corporation. All rights reserved.
Table 2 lists the model numbers of all standard SS-L models available to order. If a model
number with a specific combination of options is not listed, check with the ordering desk
for availability. Minimum order quantities and longer lead times may apply.
TABLE 2: STANDARD SS-L MODELS AVAILABLE TO ORDER
Model SMART-Sensor Description
SS-L LCD, warm grey color
SS-L-BL LCD with LED back light
SS-L-BL-CO2
LCD with LED back light, 0-2000 ppm
CO
2
sensor
SS-L-BL-CO2-H
LCD with LED back light, 0-2000 ppm
CO
2
sensor, ± 2% humidity
sensor
SS-L-BL-CO2-H-OC
LCD with LED back light, 0-2000 ppm
CO
2
sensor, ± 2% humidity
sensor, PIR Motion Sensor
SS-L-BL-D LCD with LED back light, degrees C/F toggle switch
SS-L-BL-H LCD with LED back light, ± 2% humidity sensor
SS-L-BL-H-IO LCD with LED back light, ± 2% humidity sensor, 2 dry contact
Inputs, and 2 TRIAC Outputs
SS-L-BL-IO LCD with LED back light, 2 dry contact Inputs, and 2 TRIAC
Outputs
SS-L-BL-OC LCD with LED back light, PIR Motion Sensor
SS-L-CO2
LCD with 0-2000 ppm
CO
2
sensor
SS-L-CO2-H
LCD with 0-2000 ppm
CO
2
sensor, ± 2% humidity sensor
SS-L-CO2-H-IO
LCD with 0-2000 ppm
CO
2
sensor, ± 2% humidity sensor, 2 dry
contact Inputs, and 2 TRIAC Outputs
SS-L-CO2-H-OC
LCD with 0-2000 ppm
CO
2
sensor, ± 2% humidity sensor, PIR
Motion Sensor
SS-L-CO2-IO
LCD with 0-2000 ppm
CO
2
sensor, 2 dry contact Inputs, and 2
TRIAC Outputs
SS-L-CO2-OC
LCD with 0-2000 ppm
CO
2
sensor, PIR Motion Sensor
SS-L-D LCD with degrees C/F toggle switch
SS-L-H LCD with ± 2% humidity sensor
SS-L-H-IO LCD with ± 2% humidity sensor, 2 dry contact Inputs, and 2
TRIAC Outputs
SS-L-H-OC LCD with ± 2% humidity sensor, PIR Motion Sensor
SS-L-IO LCD with 2 dry contact Inputs, and 2 TRIAC Outputs
SS-L-OC LCD with PIR Motion Sensor
The SS-L-CO2 model does not have an RJ11 port for SMART-Net
™
wiring, but does have an
RJ11 port for connection to an X-Port-2
™
.
