Table 18 describes the configuration parameters that can be accessed using the MSet
Setup Tool in each controller.
TABLE 18: SS-L ONBOARD MSET SETUP TOOL CONFIGURATION PARAMETERS
Parameter Range Selection
ADDR 1–124
RCP Controller Address (BACnet
®
MAC address)
BAUD
9600, 192,
384, 768
9600 EIA-485 network baud = 9.6 kbps
192 EIA-485 network baud = 19.2 kbps
384 EIA-485 network baud = 38.4 kbps
768 EIA-485 network baud = 76.8 kbps
SUBNET
No, Yes
No home network = main network
Yes home network = subnetwork
LAST
----, Last
---- not highest physical address on RCP network
Last highest physical address on RCP network
BACNET
Yes, No
Yes
communication protocol = BACnet
®
No communication protocol = RCP
UPDATE
No, Yes
No configuration maintained in SS-L buffer only
Yes configuration sent to controller
