The en
gi
ne Section F
8 Remove
two;\
UNC bolts, and lockwashers,
and remove camshaft retaining plate.
9 Unscrew
two
i UNC set screws and remove
front engine mounting
plate from cylinder
block, including
gasket.
10 Push the tappets in turn
up
through the
cylinder block and carefully
withd
r
aw
the
camshaft.
Fi
gure
18
Removing camsha
ft
rear bearing
1 Pilot 3 Mandrel
2
Bear
ing 4 Horseshoe
Fi
g
ur
e 19 Removing camshaft centre bearing
11
Replace in rever
se
order,
fitt
ing n
ew
gaskets where applicable.
13
Not e : When refitting distributor drive shaft
ensure the
large ·
o·
of
the
dr
iving gear offset
dog
is facing towards the block at
No
. 1 piston.
The camshaft retaining
plate, fitted
as
original
equipment is 4·
621
mm
(0
·1
82in)
thick. A
service
plate 5·258mm (0·207in) thick is
available to conteract any end float.
