4-46 DURADRIVE HDC01.1 Drive Controller DURADRIVE Drive Controllers
DOK-DURADR-HDC01.1****-PR02-EN-P
AP5364F1.FH7
A1 A2 A3
TM+
TM-
BR+
BR-
HDC
PE
X5
connector
case
A
B
C
D
AC motor
M
3
U1
V1
W1
X1 X2
temperature
dependent resistance
T1
T2
holding
brake
U
BR-
BR+
G
E
F
H
I
Fig. 4-76: Connection of motor cable, holding brake and temperature monitor
for motors with connector box
Note: The cable designations and all details on making cables are
outlined in the cable or motor document.
