Ricoh Aficio MP C3001 Service Manual

ELECTRICAL COMPONENT DESCRIPTION
B408 14 SM
Symbol Name Function Index No.
SOL3
Positioning
Roller
Moves the positioning roller.
13
Switches
SW1
Lower Tray
Upper Limit
Detects when the lower tray is at its upper limit
position.
9
SW2
Front Door
Safety
Cuts the dc power when the front door is
opened.
6
SW3
Upper Cover Cuts the dc power when the upper cover is
opened.
1
PCBs
PCB1
Main Controls the finisher and communicates with the
copier/printer.
28

Ricoh Aficio MP C3001 Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Paper Capacity	1, 200 sheets
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Copy Resolution	600 x 600 dpi
Paper Capacity (Maximum)	4, 400 sheets
Memory (Standard)	1 GB
Hard Drive	160 GB
Fax Speed	33.6 kbps
Print Speed	30 ppm
Connectivity	USB, Ethernet
Copy Speed	30 ppm (mono) / 30 ppm (color)
Paper Size	A3, A4, A5, B4, B5
Memory (Maximum)	1.5 GB
Max Paper Size	A3
Operating System Compatibility	Windows, Mac
