Ricoh Aficio MP C3001 Service Manual

FCU
D393 22 SM
2. REPLACEMENT AND ADJUSTMENT
2.1 FCU
1. When you replace the FCU board, remove the MBU board from the old FCU board and
install it on the new FCU board.
2. Set the correct date and time with the User Tools: User Tools > System Settings >
Timer Setting > Set Date/Time.
 Do not turn off the battery switch (SW1).
 Do SP6101 to print the system parameters, and check the settings.

Ricoh Aficio MP C3001 Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Paper Capacity	1, 200 sheets
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Copy Resolution	600 x 600 dpi
Paper Capacity (Maximum)	4, 400 sheets
Memory (Standard)	1 GB
Hard Drive	160 GB
Fax Speed	33.6 kbps
Print Speed	30 ppm
Connectivity	USB, Ethernet
Copy Speed	30 ppm (mono) / 30 ppm (color)
Paper Size	A3, A4, A5, B4, B5
Memory (Maximum)	1.5 GB
Max Paper Size	A3
Operating System Compatibility	Windows, Mac
