Ricoh Aficio MP C3001 Service Manual

Fax Unit (D545)
SM 3 D545
Fax option
Type C5501
D545
1.1.2 INSTALLATION PROCEDURE
 Before installing this fax unit:
 Print out all data in the printer buffer.
 Turn off the main power switch and disconnect the power cord and the network
cable.
1. Remove the controller box cover [A] (
x 3).
2. Remove the controller box [B] (
x 5).
3. Attach the FCU I/F board bracket [A] to the controller board (
x 2).

Ricoh Aficio MP C3001 Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Paper Capacity	1, 200 sheets
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Copy Resolution	600 x 600 dpi
Paper Capacity (Maximum)	4, 400 sheets
Memory (Standard)	1 GB
Hard Drive	160 GB
Fax Speed	33.6 kbps
Print Speed	30 ppm
Connectivity	USB, Ethernet
Copy Speed	30 ppm (mono) / 30 ppm (color)
Paper Size	A3, A4, A5, B4, B5
Memory (Maximum)	1.5 GB
Max Paper Size	A3
Operating System Compatibility	Windows, Mac
