Ricoh Aficio MP C3001 Service Manual

DIP Switches
B793 30 SM
1.5 DIP SWITCHES
SW100: Adjust the staple position for booklet mode
No. Function
1 ON: 0.3 mm
2 ON: 0.6 mm
3 ON: 1.2 mm
4
Direction
OFF: Towards the trailing edge, ON: Towards the leading edge
SW101: Adjust the fold position
No. Function
1 ON: 0.2 mm
2 ON: 0.4 mm
3 ON: 0.8 mm
4
Direction
OFF: Towards the trailing edge, ON: Towards the leading edge
SW102: Move the tray position
No. Function
1
OFF → ON → OFF
Turn the switch from off to on, then turn it to off again. Then, the tray moves down to
the shipping position
2 Not used
 After you change any of these dip switch settings, open and close the finisher
cover to activate the new setting. It is not necessary to turn the main power off/on.
