G3 Interface Unit (D393)
D545 14 SM
1.3 G3 INTERFACE UNIT (D393)
1.3.1 COMPONENT CHECK
Check the quantity and condition of the components against the following list.
No. Description Q'ty
1 SG3 Interface Unit 1
2 Modular Bracket for SG3 1
3 Clamp 2
4 Clamp 4
5 Screw: M3x6 6
6 Ferrite Core 1
7 Telephone Cable (NA only) 1
8 Flat Cable 1
9 Harness 1
10 EMC Address Decal (EU only) 1
11 FCC Decal (NA only) 1
