Ricoh Aficio MP C3001 - Ozone Filter and Dust Filter; Ozone Filters for the Scanner Unit

Exterior Covers
D086/D087 4-22 SM
4.4.9 OZONE FILTER AND DUST FILTER
Ozone filters for the scanner unit
1. Scanner right cover [A] (
x 2)
 Loosen the top-right screw of the rear cover.
2. Right top cover [B] (
x 1)
3. Ozone filters [A] in the right top cover.
