Setting Description Setting value
Phase 2
Security Protocol
Specify the security protocol
to be used in Phase 2.
To apply both encryption and
authentication to sent data,
specify "ESP" or "ESP+AH".
To apply authentication data
only, specify "AH".
(auto setting)
• ESP
•
AH
• ESP+AH
Phase 2
Authentication Algorithm
Specify the authentication
algorithm to be used in phase
2.
(auto setting)
• HMAC-MD5-96
•
HMAC-SHA1-96
• HMAC-SHA256-128
• HMAC-SHA384-192
• HMAC-SHA512-256
Phase 2
Encryption Algorithm
Permissions
Specify the encryption
algorithm to be used in phase
2.
(auto setting)
• Cleartext (NULL
encryption)
• DES
• 3DES
• AES-128
• AES-192
• AES-256
Phase 2
PFS
Specify whether to activate
PFS. Then, if PFS is activated,
select the Diffie-Hellman
group.
(auto setting)
• Inactive
•
1
• 2
• 14
Phase 2
Validity Period
Specify the time period for
which the SA settings in phase
2 are valid.
Specify a period (in seconds)
from 300 (5min.) to 172800
(48 hrs.).
5. Enhanced Network Security
156

Ricoh Aficio MP C5502 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Multiple Copy	Up to 999 copies
Max Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Hard Disk Drive	250 GB
Power Consumption (Maximum)	1.7 kW
Type	All in One Printer
Print Speed	55 pages per minute
Copy Speed	55 copies per minute
Zoom	25% to 400%
Scan Resolution	600 dpi
Fax Resolution	200 x 200 dpi
Original Capacity	100 sheets
Standard Paper Capacity	1, 200 sheets
Memory	1.5 GB RAM
Interface	USB 2.0, Ethernet
Network Protocols	TCP/IP
Operating Systems Supported	Windows, Mac, Linux
Power Source	AC 120V, 60Hz
Paper Weight	52 – 256 g/m²
