Encryption key manual settings items
Setting Description Setting value
Address Type
Specify the address type for
which IPsec transmission is
used.
• Inactive
•
IPv4
• IPv6
• IPv4/IPv6 (Default
Settings only)
Local Address
Specify the machine's address.
If you are using multiple IPv6
addresses, you can also
specify an address range.
The machine's IPv4 or IPv6
address.
If you are not setting an
address range, enter 32 after
an IPv4 address, or enter 128
after an IPv6 address.
Remote Address
Specify the address of the
IPsec transmission partner.
You can also specify an
address range.
The IPsec transmission
partner's IPv4 or IPv6 address.
If you are not setting an
address range, enter 32 after
an IPv4 address, or enter 128
after an IPv6 address.
Encapsulation Mode
Select the encapsulation
mode.
• Transport
•
Tunnel
(Tunnel beginning address -
Tunnel ending address)
If you select "Tunnel", set the
"Tunnel End Point", the
beginning and ending IP
addresses. In "Tunnel End
Point", set the same address
for the beginning point as you
set in "Local Address".
SPI (Output)
Specify the same value as
your transmission partner's SPI
input value.
Any number between 256
and 4095
