Quick Reference
SM 4-57 J012/J013/J014
Trouble-
shooting
4.6 QUICK REFERENCE
This alphabetized list shows important functions needed by service technicians. For more
detailed information please refer to either "5. Service Tables" or "4. Troubleshooting.”
Item Path
ADF. Adjustment 1. [Menu]> [#]> [*]> [Yes]> "1. SERVICE'S CHOICE"
2. [#] or [%] > "2. ADJUST"> [Yes]> "CCD MAIN
ZOOM"
3. [#] or [%] > To select "ADF. SUB ZOOM", "ADF.
MAIN REGIST", "ADF. SUB REGIST1", "ADF. SUB
REGIST2.”
4. For more see "Service Mode" in "5. Service Tables"
ADF. Feed Test 1. [Menu]> [#]> [*]> [Yes]> "1. SERVICE'S CHOICE"
2. [#] or [%] > "6. FUNCTION"> [Yes]> "ADF. FEED
TEST"
Adjust Paper Feed 1. [Menu]> "System Settings?"
2. [#] or [%] > "Maintenance?"> [Yes]> "1 Nozzle
Check?"
3. [#] or [%] > "5 Adj. Paper Feed?" > [Yes]
4. For more see "Adjust Paper Feed" in "4.
Troubleshooting.”
Auto Reset Time [Menu]> "System Settings"> [Yes]> "1. Auto Reset Time?"
Bit SW Settings (Hardware) 1. [Clear Modes]> [107]> [Clear/Stop]> "Service Menu">
[Yes]> "Bit Switch"> [Yes]
2. For more see "Changing Bit Switch Settings" in "5.
Service Tables.”
Bit SW Settings (Soft Bit
SW Settings for Fax)
1. [Menu]> [#]> [*]> [Yes]> "1. SERVICE'S CHOICE"
2. [#] or [%] > "7. SOFT SETTING"> [Yes]
3. For more see "Service Mode Menus" in "5. Service
Tables.”
