Ricoh J012 - Load Paper in the Paper Feed Unit

Options
SM 1-29 J012/J013/J014
Installation
4. Pull the paper cassette partially out of the PFU.
5. Remove the paper cassette cover from its wrapping and set it on the PFU.
6. Position the PFU where the machine will be set up.
7. Mount the cover on the paper tray.
8. Align the connection point holes in the bottom of the machine with the pegs of the paper
tray while you hold the machine as shown.
9. Slowly set the machine on top of the PFU.
Load Paper in the Paper Feed Unit
1. Raise the paper tray slightly and pull it toward you to remove it.
2. Remove the paper tray cover.
3. Pinch the tabs of the bottom fence then slide it completely forward.
4. Fan a stack of paper to remove static cling.
5. Load the paper into the cassette.
6. Add paper until it as far as the load limit marks.
 To prevent paper jams, never load paper higher than the load limit mark.
7. Pinch the tabs of the bottom fence. Then move it to the edge of the stack.
