Ricoh J012 - Encoder Readings; Board Temperature Sensors; Group 6000

SP Mode Service Tables
J012/J013/J014 5-78 SM
Encoder Readings
5417 INPUT CHK MENC Horizontal Encoder
Use this SP to display the current reading of the main scan encoder.
5418 INPUT CHK SENC Vertical Encoder
Use this SP to display the current reading of the sub scan encoder.
Board Temperature Sensors
5419 INPUT CHK PTEMP PSU Ambient Temperature Sensor
Displays the temperature reading of the PSU ambient temperature sensor.
Note: At present nothing displays because there is no temperature sensor in the
PSU.
Units: 0.1
o
C
5420 INPUT CHK DTEMP Drive Board Temperature Sensor
Displays the temperature reading of the temperature sensor in the DRV board
circuits.
Units: 0.1
o
C
5.3.7 GROUP 6000
Not Used
