SP Mode Service Tables
SM 5-79 J012/J013/J014
Service
Tables
5.3.8 GROUP 7000
Display Charge Count
7000 CHG CNT:S:P:M Single Counter: Monochrome Application
7001 CHG CNT:S:P:L Single Counter: Multi-Level Color Application
7002 CHG CNT:S:P:C Single Counter: Color Application
7003 CHG CNT:W:P:M Double Counter: Monochrome Application
7004 CHG CNT:W:P:L Double Counter: Multi-Level Color Application
7005 CHG CNT:W:P:C Double Counter: Color Application
Use this sensor to display the charge counts.
Display Coverage Count
7006 COVER CNT:P:M Monochrome Application
7007 COVER CNT:P:L DColor Application
7008 COVER CNT:P:C Multi-Level Color Application
Use this sensor to display the charge counts.
