SP Mode Service Tables
J012/J013/J014 5-72 SM
5102 CARRIAGE ADJUST Set Printer n Carriage Adjust Mode
Use this SP to adjust the print head gap after print head replacement and print the
Nozzle Check pattern.
Carriage Adjustment Mode Flow
Before executing this menu, you must execute the carriage replacement mode.
1. Print the print head gap adjustment chart (High Speed).
2. Adjust the gap (High Speed).
3. Print the print head gap adjustment chart (High Speed).
4. Print the print head gap adjustment chart (Std. (Speed Priority). Std. (Quality
Priority)).
5. Adjust the gap (Std. (Quality Priority, Std. (Speed Priority)).
6. Print the print head gap adjustment chart (Std. (Speed Priority). Std. (Quality
Priority)).
7. Print the print head gap adjustment chart (High Quality).
8. Adjust the gap (High Quality).
9. Print the print head gap adjustment chart (High Quality).
10. Print the Nozzle Check test pattern.
5200 PRINT SMC Print an Engine Maintenance Summary
Use this SP to print an engine maintenance summary. You need at least 8 sheets
of paper to do this print. It will take at least 3 minutes before the print will start.
5300 DUMMY NUMBER Set a Dummy Number
Use this SP to set the dummy number.
