Ricoh SP 3710SF - Specifying Encryption Key Exchange Settings; Specifying Ipsec Settings on the Computer

Specifying Encryption Key Exchange Settings
• This function is available only when an administrator password is specified.
1. Start the web browser and access the machine by entering its IP address.
2. Click [IPsec Settings].
3. Click the [IPsec Policy List] tab.
4. Select the number of the setting you want to modify in the list, and then click [Change].
5. Modify the IPsec related settings as necessary.
6. Enter the administrator password, and then click [Apply].
7. Click the [IPsec Global Settings] tab, and then select [Active] in [IPsec Function].
8. If necessary, specify [Default Policy], [Broadcast and Multicast Bypass], and [All ICMP
Bypass] also.
9. Enter the administrator password, and then click [Apply].
• An administrator password can be specified in the [Administrator] tab.
Specifying IPsec Settings on the Computer
Specify exactly the same settings for IPsec SA settings on your computer as are specified for the IPsec
Settings on the machine. Setting methods differ according to the computer's operating system. The
following procedure is based on Windows 10 in an IPv4 environment as an example.
1. On the [Start] menu, click [Control Panel], [System and Security], and then click
[Administrative Tools].
2. Double-click [Local Security Policy], and then click [IP Security Policies on Local
Computer].
3. In the "Action" menu, click [Create IP Security Policy...].
The IP Security Policy Wizard appears.
4. Click [Next].
5. Enter a security policy name in "Name", and then click [Next].
6. Clear the "Activate the default response rule" check box, and then click [Next].
7. Select "Edit properties", and then click [Finish].
8. In the "General" tab, click [Settings...].
12. Appendix
460
