Note
The decimal point setting must be identical in the min. and max. range.
View in parameter assignment mode (example):
5.5.23 Analog amplifier
Fashion: Classic:
Short description
This SFB amplifies an analog input value and returns it at the analog output.
Connection
Description
Input Ax
Input the analog signal to be
amplified at input Ax.
Use the analog inputs
AI1...AI8, the analog outputs
AQ1 and AQ2.
AI1..AI8: 0 - 10 V corresponds
with 0 - 1000 (internal value).
Parameter
A: Gain
