5.Digital/Analog D: digital DA: digital/analog
6.Output type R: relay TP: “NPN” transistor；TN :“PNP” transistor
2.2 Hardware model selection
PR-6 Series CPU Units (None expandable)
Model
Expansion
Supply voltage
Inputs
Outputs
High-speed
count
PWM
HMI
RTC
PR-6AC-R
no
AC110~AC240V/
DC110-DC240V
4 digital
2 relays (10A)
no
no
no
yes
PR-6DC-DA-R
no
DC12-24V
4 digital/4(0...10V)
2 relays (10A)
no
no
no
yes
PR-12 Series CPU Units(None expandable)
Model
Expansio
n
Supply voltage
Inputs
Outputs
High-speed count
PWM
HMI
RTC
PR-12AC-R-HMI
no
AC110~AC240V
8 digital
4 relays (10A)
no
no
yes
yes
PR-12AC-R-E-CAP
no
AC110~AC240V
8 digital
4 relays (10A)
no
no
no
yes
PR-12DC-DA-R-HMI
no
DC12-24V
4(0...10V)+4 digital
4 relays (10A)
4(I5-I8)(60KHZ)
no
yes
yes
PR-12DC-DA-R-E-CAP
no
DC12-24V
4(0...10V)+4 digital
4 relays (10A)
no
no
no
yes
PR-12DC-DA-TN-HMI
no
DC12-24V
4(0...10V)+4 digital
4Transistor(0.3A/
PNP)
4 (I5-I8)(60KHZ)
Yes(10KHZ)
yes
yes
PR-14 Series CPU Units(Expandable)-built-in RS485 port
Model
Expansion
Supply voltage
Inputs
Outputs
High-speed count
PWM
HMI
RTC
PR-14AC-R-HMI
yes
AC110~AC240V
/DC110-DC240V
10 digital
4 relays (10A)
no
no
yes
yes
PR-14DC-DA-R-HMI
yes
DC12-24V
6(0...10V)/6digit
al+4 digital
4 relays (10A)
4(I7-IA)(60KHZ)
no
yes
yes
PR-18 Series CPU Units(Expandable)
Model
Expansion
Supply voltage
Inputs
Outputs
High-speed count
PWM
HMI
RTC
PR-18AC-R-HMI
yes
AC110~AC240V
/DC110-DC240V
12 digital
6 relays (10A)
no
no
yes
yes
PR-18DC-DA-R-HMI
yes
DC12-24V
6(0...10V)/6digit
al+6 digital
6 relays (10A)
4(I9-IC)(60KHZ)
no
yes
yes
PR-18DC-DA-RT-HMI
yes
DC12-24V
6(0...10V)/6digit
al+6 digital
4 relays (10A)+
2 transistor(0.3A)
4(I9-IC)(60KHZ)
yes(10khz)
yes
yes
PR-24 Series CPU Units(Expandable)-built-in RS485 port
Model
Expansion
Supply voltage
Inputs
Outputs
High-speed
count
PWM
HMI
RTC
