2.3 Structure & dimension
1. PR-6 Series CPU&EXM-E Series Extension
1.Power supply 2. Input 3. Program port for applied to ELC-6 CPU 4.Output
2. Standard PR-12 series with LCD model:
1.Power supply&Input terminals 2. Program Port(can be used as RS232 port with ELC-RS232 or RS485
port with PRO-RS485) 3.HMI/LCD panel 4.keypad 5.Output terminals
3. Economic PR-12 series without LCD model:
