5.5.46 Comport Status
Fashion: Classic:
Short description
This function block is used to monitor the communication status of the RS232 (programming port),
RS485 port, Ethernet/WIFI port.
With the text message block, we can insert the com port status from such function block for displaying on
the LCD.
Enable the function block if a HI level at En input pin and if a trigger from HI to
LOW, the function would be disabled.
Channel: RS232
RS485
Ethernet/WIFI
Timeout:1—100s
Monitor type: TX
RX
TX+RX
When a HI level at the En pin and the timeout is reached the output will be HI,
and it will be reset when the En is switched.
